Commercial Side mount Back Up Color CMOS Camera with 180 degree Wide Angle Night Vision

Name: Commercial Side mount Back Up Color CMOS Camera with 180 degree Wide Angle Night Vision
Brand: Vanwin Tracking
Price: 1 USD

China Commercial Side mount Back Up Color CMOS Camera with 180 degree Wide Angle Night Vision wholesale

Brand Name : Vanwin Tracking

Model Number : VW-C119

Certification : CE/FCC/RoHS

Place of Origin : Shenzhen, China

MOQ : 5pcs

Price : negotiated

Payment Terms : Western Union, T/T, Paypal

Supply Ability : 5,000pcs per month; Commercial Side mount Back Up Color CMOS Camera with 180 degree Wide Angle Night Vision

Delivery Time : 2-3 days for samples, 5-10 days for large orders

Packaging Details : Neutral carton box package by default

Type : 360 degree mini camera

Application : Front view / Rearview / Sideview

TV system : PAL or NTSC

Voltage : DC8~35V

Connector : 4 pin aviation,square, BNC connector, BWM

Warranty : 12 months

Resolution : CCD 600TVL/960P for option

View angle : horizontal angle 180°±5°

IR lights : 9pcs

Waterproof : yes

Angle : 180 degree in horizontal

Material : Plastic housing

Contact Now

Commercial Side mount Back Up Color CMOS Camera with 180 degree Wide Angle Night Vision

It can be used with mobile DVR system or reversing system for front view, side view and backview. It's very welcomed with its good night vision, wide degree, and special mold. It's very sturdy and not easily broken.

Compatibility

Camera is compatible with Back Up Camera Systems, multi-input monitors and Mobile DVR.
Camera is designed for side mounting
Ideal for Heavy Duty and Commercial Vehicles (Truck, RV, Bus, Van, Tractor, Trailer, Crane, Dirt Wagon, etc)

Features

High Resolution Side Mount Camera
Camera is not adjustable within housing
1/3" Color CMOS Image Sensor
CCD 600 TV lines or 960P AHD of resolution
180 degrees Wide Angle Camera - Blind Spot reduced
Automatic IR Infrared LED Night Vision
Weatherproof, Waterproof, Shockproof and High Temperature Resistance
Side Mount Application
High impact plastic side mount housing that prevents permanent damage to the camera
Rubber base for vibration isolation
4 Pin Connector
Dimensions: 79(L)*43(H)*36(w) mm

Main Specifications

Image Sensor	1/3 AR0130 CMOS
Video System	PAL/NTSC
Pixels	PAL:1280(H)×960(V)
Pixels	NTSC:1280(H)×960(V)
Horizontal Resolution	600 TVL/960P
Min Illumination	0.0001 LUX / F1.2
SNR	≥46dB
Electronic Shutter	1/50-1/10000(S); 1/60～1/100000s
Video Output	1.0V±0.5Vp-p 75Ω
View Angle	1.9/850 horizontal angle 180°±5°
Working Voltage	DC8-35V
Consumption	100mA±10%
Display image	Mirror/normal optional
MIC	Optional
Camera Len	f:3.6mm

Application

1. Taxi or small car, bus, truck, van and ect.

2. Frontview, sideview, backview

2. MDVR, Reversing system

Commercial Side mount Back Up Color CMOS Camera with 180 degree Wide Angle Night Vision
